Nguồn DC (0 ~ 30V/0~5A) QJE QJ3005XE

Output Voltage : 0 ~ 30V
Output Current : 0 ~ 5A
Resolution : 100mV/10mA
Input Voltage : 220VAC – 50/60Hz
Source  effect  CV≤1×10-4+5mV
CC≤1×10-4 +5mA
Load   effect CV≤1×10-4 +5mV
CC≤1×10-4 +5mA
 Ripple&Noise CV≤1mV rms/3mVp-p
Dimensions (WxHxD) : 130x190x270mm
Weight (kg) : 5.3
Features :
+ Utilizing SMD technology
+ With the function of voltage and current pre-set
+ With on-off switch for DC output
+ Highly accurate digital dislay for voltage ouput
+ Large LED for voltage output
+ With S+, S- sampling connectors
+ Extention output connectors
